Description
4-stroke, floating, self-priming portable motor pump.
Pump made of aluminum alloy with built-in filter and anti-vibration feet.
The float is made of high-density, unsinkable polyurethane foam.
FLOATING MOTOR PUMPS
4-stroke, floating, self-priming portable motor pump.
Pump made of aluminum alloy with built-in filter and anti-vibration feet.
The float is made of high-density, unsinkable polyurethane foam.
Applications
Fire protection from water sources such as swimming pools, rivers, lakes, reservoirs, etc., water pumping, rapid refueling of tanker trucks, and evacuation of contaminated water.
Characteristics
It requires neither a suction tube nor a priming device. The float is required from 15 cm of water. It is seawater resistant and can handle very heavy waters. It is very easy to handle, as it can be safely transported by a single person.
| MODEL | 3.5 HP | 6 HP |
| Maximum flow rate (l/min) | 700 | 1298 |
| Maximum pressure (bar) | 1,7 | 2,5 |
| Start | manual | manual |
| Possibility of running dry | Yeah | Yeah |
| Removable float | Yeah | Yeah |
| 4-stroke engine | Briggs & Stratton | Kawasaki |
| Tank capacity in liters | 0,85 | 2 |
| Autonomy | 40 min. | 60 min. |
| Length Dimensions | 89 cm. | 89 cm. |
| mm. | 870 | 870 |
| High | 600 | 600 |
| Volume (m³) | 398 | 398 |
| Outlet diameter | 70 mm. | 70 mm. |
Documentation
Technical sheet
